HIKVISION DS-2CV2027G0-LDW 2 MP AcuSense ColorVu Outdoor WDR Fixed Bullet Network Camera
Couldn't load pickup availability
Do you have any question about the Products?Contact us now via sales@hikdistribution.com.
 |
 |
Ask Our Experts Text Chat | Email |
|
Important Information Regarding Order and Pricing
|
Quality Certifications: |
2 MP AcuSense ColorVu Outdoor WDR Fixed Bullet Network Camera
- 24/7 Colorful imaging
- High quality imaging with 2 MP resolution
- False alarm reduction through human and vehicle target classification based on deep learning
- Realizing Wi-Fi connection and easy installation
- Provides real-time security via built-in two-way audio
- Efficient H.265 compression technology
- Water and dust resistant (IP66)
- Built-in micro SD/SDHC/SDXC card slot, up to 256 GB
Available models:
Product Data
- Camera
- Image Sensor1/2.8" Progressive Scan CMOS
- Min. IlluminationColor: 0.0005 Lux @ (F1.0, AGC ON)
- Shutter Speed1/3 s to 1/100,000 s
- Slow ShutterYes
- Wide Dynamic Range120 dB
- Angle AdjustmentPan: 0～ to 360～, tilt: 0～ to 90～, rotate: 0～ to 360～
- Lens
-
Lens Type & FOV
2.8 mm, horizontal FOV: 106～, vertical FOV: 55～, diagonal FOV: 126～
4 mm, horizontal FOV: 83～, vertical FOV: 44～, diagonal FOV: 99～
- ApertureF1.0
- Lens MountM12
- Illuminator
- Smart Supplement LightYes
- Visual AlarmYes
- White Light RangeWarm white LEDs (3000 K), up to 30 m
- Video
- Max. Resolution1920 ℅ 1080
-
Main Stream
50Hz: 25 fps (1920 ℅ 1080, 1280 ℅ 720)
60Hz: 30 fps (1920 ℅ 1080, 1280 ℅ 720)
-
Sub Stream
50Hz: 25 fps (640 ℅ 360)
60Hz: 30 fps (640 ℅ 360)
- Video Compression Main stream/Sub-stream: H.265/H.264
- Video Bit Rate32 Kbps to 8 Mbps
- H.264 TypeBaseLine Profile/Main Profile/High Profile
- H.265 TypeMain Profile
- Stream TypeMain stream and sub-stream
- Audio
- Environment Noise FilteringYes
- Audio Sampling Rate8 kHz/16 kHz
- Audio Compression G.711/G.722.1/G.726/MP2L2/PCM
- Audio Bit Rate64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-160Kbps(MP2L2)
- Network
- Simultaneous Live ViewUp to 6 channels
- APISDK
- ProtocolsTCP/IP, ICMP, HTTP, FTP, DHCP, DNS, DDNS, RTP, RTSP,RTCP, NTP, UPnP, IGMP, QoS, IPv6, UDP, Bonjour
-
User/Host
Up to 32 users
3 levels: administrator, operator and user
- SecurityPassword protection, complicated password, HTTPS encryption,watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for open network video interface, RTP/RTSP OVER HTTPS, Security Audit Log, TLS 1.2
- Network StorageMicroSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS)
- ClientiVMS-4200, Hik-Central
-
Web Browser
Plug-in required live view: IE 8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11;
Plug-in free live view: Chrome 45.0+, Firefox 52.0+
- Wi-Fi
- Encryption Mode64/128-bit WEP, WPA-EAP/WPA2-EAP, WPA-PSK/WPA4-PSK
- Wi-Fi ProtocolIEEE802.11b, 802.11g, 802.11n
- Frequency Range2.4 GHz - 2.4835 GHz
- Channel Bandwidth 20/40 MHz
-
Modulation
802.11b: CCK, QPSK, BPSK
802.11g/n: OFDM
- Wireless RangeUp to 120 m (The performance varies based on actual environment)
- Image
- Day/Night SwitchDay/Night/Auto/Schedule
- Image EnhancementBLC, HLC, 3D DNR
- Image SettingsSaturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser
- Interface
- On-board StorageBuilt-in micro SD/SDHC/SDXC slot, up to 256 GB
- Hardware ResetYes
- Communication Interface1 RJ45 10M/100M self-adaptive Ethernet port
- Event
- Basic Event Motion detection, audible alarm output, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
- Smart EventIntrusion detection, line crossing detection, region entrance detection, region exiting detection
- General
- Linkage MethodUpload to NAS/memory card, notify surveillance center, trigger record, trigger capture, strobe light, audiable warning
- Online UpgradeYes
- Firmware Version5.5.134
- General FunctionOne-key reset, anti-flicker, heartbeat, mirror, password protection, watermark, IP address filter, flash log, pixel counter
- Software ResetYes
- Storage Conditions-30 ～C to 60 ～C (-22 ～F to 140 ～F)
- Startup and Operating Conditions-30 ～C to 60 ～C (-22 ～F to 140 ～F)
- Power Supply12 VDC ㊣ 25%, reverse polarity protection
- Power Consumption and Current12 VDC, 0.6 A, max. 7.0 W
- Power Interface?5.5 mm coaxial power plug
- MaterialFront cover: metal, back cover: plastic
- Camera Dimension175.6 ℅ 73.0 ℅ 89.1 mm (6.91" ℅ 2.87" ℅ 3.51")
- Package Dimension260 ℅ 125 ℅ 125 mm (10.24" ℅ 4.92" ℅ 4.92")
- Camera Weight490 g (1.08 lb.)
- With Package Weight824 g (1.82 lb.)
- Approval
-
EMC
FCC SDoC (47 CFR Part 15, Subpart B);
CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);
RCM (AS/NZS CISPR 32: 2015);
IC VoC (ICES-003: Issue 6, 2016);
KC (KN 32: 2015, KN 35: 2015)
-
RF
FCC ID (FCC Part 15.247(BT or 2.4G));
IC ID (RSS-247(BT or 2.4G));
CE-RED (EN 301489-1 V2.1.1(BT or 2.4G); EN 301489-17 V3.1.1(BT or 2.4G); EN 300328 V2.1.1(BT or 2.4G); EN 62311:2008(BT or 2.4G));
WPC (EN 301 489-1 V2.1.1(BT or 2.4G); EN 301 489-17 V3.1.1(BT or 2.4G); EN 300 328 V2.1.1(BT or 2.4G); EN 62311:2008(BT or 2.4G); EN 55032:2015; EN 61000-3-2:2014; EN 61000-3-3:2013; EN 50130-4:2011 +A1:2014);
KC (KN 32:2015; KN 35: 2015; KN 301489-1; KN 301489-17);
ICASA (EN 301 489-1 V2.1.1(BT or 2.4G); EN 301 489-17 V3.1.1(BT or 2.4G); EN 300 328 V2.1.1(BT or 2.4G); EN 62311:2008(BT or 2.4G); EN 55032:2015; EN 61000-3-2:2014; EN 61000-3-3:2013; EN 50130-4:2011 +A1:2014; EN 60950-1:2005 + Am 1:2009 + Am 2:2013)
-
Safety
UL (UL 60950-1);
CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);
CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);
BIS (IS 13252(Part 1):2010+A1:2013+A2:2015);
LOA (IEC/EN 60950-1)
-
Environment
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Reach Regulation (EC) No 1907/2006
- ProtectionIP66 (IEC 60529-2013)
