2 MP Motorized Varifocal PT Web Camera
- 2 MP CMOS
- High quality imaging with 1920 × 1080 resolution
- 3.1 mm to 15.5 mm varifocal lens, auto focus
- Min. Illumination: 0.1 Lux @ (F1.2, AGC ON)
- Clear imaging against strong back light due to 120 dB true WDR technology
- AGC for self-adaptive brightness
- Support remote control
- Built-in microphone with clear sound
Available models:
Product Data
- Camera
- Image Sensor2 MP CMOS
- Signal SystemPAL/NTSC
- Max. Resolution1920 × 1080
-
Frame Rate
MJPEG_/p>
640×480@30fps/25fps
160×120@30fps/25fps
176×144@30fps/25fps
320×240@30fps/25fps
352×288@30fps/25fps
432×240@30fps/25fps
640×360@30fps/25fps
800×448@30fps/25fps
800×600@30fps/25fps
864×480@30fps/25fps
960×720@30fps/25fps
1024×576@30fps/25fps
1280×720@30fps/25fps
1920×1080@30fps/25fps
YUV_/p>
640×480@30fps
160×120@30fps
176×144@30fps
320×240@30fps
352×288@30fps
432×240@30fps
640×360@30fps
800×448@30fps
800×600@25fps
864×480@29fps
960×720@17fps
1024×576@20fps
1280×720@13fps
1600×896@8fps
1920×1080@5fps
- Min. Illumination0.1 Lux @ (F1.2, AGC ON)
-
Shutter Time
PAL: 1/25 s to 1/50,000 s
NTSC: 1/30 s to 1/50,000 s
- Lens3.1 mm to 15.5 mm varifocal lens
-
Field of View
Horizontal FOV: 84.9° to 20.8°
Vertical FOV: 92.8° to 23.8°
Diagonal FOV: 94° to 23.8°
- Day & NightColor
- Wide Dynamic Range≿20 dB
- Pickup Distance5 m
- Angle AdjustmentPan: -170° to 160°, Tilt:-28° to 28°
- Cable Length4.5 m
- Function
- LED IndicatorRed: Standby, Blue: Normally Working;Blue Light Flashes Twice: Preset Setting Completed;Red Light Flashes Three Times: Restore to Factory Settings.
- Audio Sampling Rate48 kHz
- White BalanceAuto
- Interface
- Video OutputUSB 2.0
- Audio InputBuilt-in Mic
-
Operating System
Recommended systems
Windows 7/8/10/11
Android 8.1 and above version
Linux 4.14 and above version
macOS 10.12 and above version
Chrome OS
- General
- Operating Conditions-10ℿto 50ℿ(-40°F to 122°F); Humidity: 90% or less (non-condensing)
- Power Supply DC12V±10%
- Consumption5.7 W MAX
- Dimension145.3 mm × 145.6 mm × 145.8 mm (5.7" × 5.7" × 5.7")
- Approx. 925 g (2.04 lb.)
- Accessory
-
Packing List
Camera (including lens cover) × 1
Remote Control × 1
Power Adapter × 1
Cable × 1
Bracket × 1
Screws × 1
Quick Start Guide × 1
- Image Sensor2 MP CMOS
- Signal SystemPAL/NTSC
- Max. Resolution1920 × 1080
-
Frame Rate
MJPEG_/p>
640×480@30fps/25fps
160×120@30fps/25fps
176×144@30fps/25fps
320×240@30fps/25fps
352×288@30fps/25fps
432×240@30fps/25fps
640×360@30fps/25fps
800×448@30fps/25fps
800×600@30fps/25fps
864×480@30fps/25fps
960×720@30fps/25fps
1024×576@30fps/25fps
1280×720@30fps/25fps
1920×1080@30fps/25fps
YUV_/p>
640×480@30fps
160×120@30fps
176×144@30fps
320×240@30fps
352×288@30fps
432×240@30fps
640×360@30fps
800×448@30fps
800×600@25fps
864×480@29fps
960×720@17fps
1024×576@20fps
1280×720@13fps
1600×896@8fps
1920×1080@5fps
- Min. Illumination0.1 Lux @ (F1.2, AGC ON)
-
Shutter Time
PAL: 1/25 s to 1/50,000 s
NTSC: 1/30 s to 1/50,000 s
- Lens3.1 mm to 15.5 mm varifocal lens
-
Field of View
Horizontal FOV: 84.9° to 20.8°
Vertical FOV: 92.8° to 23.8°
Diagonal FOV: 94° to 23.8°
- Day & NightColor
- Wide Dynamic Range≿20 dB
- Pickup Distance5 m
- Angle AdjustmentPan: -170° to 160°, Tilt:-28° to 28°
- Cable Length4.5 m
- LED IndicatorRed: Standby, Blue: Normally Working;Blue Light Flashes Twice: Preset Setting Completed;Red Light Flashes Three Times: Restore to Factory Settings.
- Audio Sampling Rate48 kHz
- White BalanceAuto
- Video OutputUSB 2.0
- Audio InputBuilt-in Mic
-
Operating System
Recommended systems
Windows 7/8/10/11
Android 8.1 and above version
Linux 4.14 and above version
macOS 10.12 and above version
Chrome OS
- Operating Conditions-10ℿto 50ℿ(-40°F to 122°F); Humidity: 90% or less (non-condensing)
- Power Supply DC12V±10%
- Consumption5.7 W MAX
- Dimension145.3 mm × 145.6 mm × 145.8 mm (5.7" × 5.7" × 5.7")
- Approx. 925 g (2.04 lb.)
-
Packing List
Camera (including lens cover) × 1
Remote Control × 1
Power Adapter × 1
Cable × 1
Bracket × 1
Screws × 1
Quick Start Guide × 1
