HIKVISION DS-U102 2 MP Motorized Varifocal PT Web Camera

In stock
SKU: DS-U102
Regular price $1,000,000.00
Our standard leading time is estimated to be 40 working days, even if it is shown as in stock, please confirm this lead time before purchasing.
Get More Information
Do you have any question about the Products?Contact us now via sales@hikdistribution.com.
Ask Our Experts
Text Chat | Email

Important Information Regarding Order and Pricing

  • The prices listed, such as $1000000 or $1,534,590.00, are placeholders and do not reflect the actual prices. These products on this page are typically specialized for project-specific requirements, and pricing depends on various factors such as the required quantity and any other project-specific requirements.
  • Please contact us to get the latest discount information (we can offer lower prices than all dealers).
  • Inventory Statement:Please note that the inventory status displayed for our products is not in real-time. We will inform you of the actual inventory status via email to ensure you have the most accurate information for your purchase decisions.
  • Minimum Order Amount Statement:For non-stock items, we have a minimum order value requirement of $3,000 USD. This threshold helps us to process your orders efficiently and provide you with the best possible service.
  • Please note that the prices mentioned are subject to the final Proforma Invoice (PI) prices, which will be provided to you after confirming your order. Additionally, the shipping costs for the products will be calculated separately and added to the total value of the order.
  • Final Price Explanation: Our prices include VAT and shipping charges. Please note that customs duties are not included.
  • If you have any further questions or need assistance, please don't hesitate to reach out. We are committed to providing you with the best price and service for your order.
  • We guarantee that the products we sell are official original products with the latest firmware versions. If you require the latest firmware for this product, please contact our customer service directly.
  • As authorized distributors, all orders and customs documents are provided by the original manufacturer. We also provide official technical support. For project-based orders, local warranty is provided by the manufacturer, while we provide warranty for dealer orders.
    If you have any other inquiries or need further clarification, please feel free to let us know. We are here to assist you.
Quality Certifications:



2 MP Motorized Varifocal PT Web Camera

  • 2 MP CMOS
  • High quality imaging with 1920 × 1080 resolution
  • 3.1 mm to 15.5 mm varifocal lens, auto focus
  • Min. Illumination: 0.1 Lux @ (F1.2, AGC ON)
  • Clear imaging against strong back light due to 120 dB true WDR technology
  • AGC for self-adaptive brightness
  • Support remote control
  • Built-in microphone with clear sound

Available models:

DS-U102

Product Data

  • Camera
  • Image Sensor2 MP CMOS
  • Signal SystemPAL/NTSC
  • Max. Resolution1920 × 1080
  • Frame Rate

    MJPEG_/p>

    640×480@30fps/25fps

    160×120@30fps/25fps

    176×144@30fps/25fps

    320×240@30fps/25fps

    352×288@30fps/25fps

    432×240@30fps/25fps

    640×360@30fps/25fps

    800×448@30fps/25fps

    800×600@30fps/25fps

    864×480@30fps/25fps

    960×720@30fps/25fps

    1024×576@30fps/25fps

    1280×720@30fps/25fps

    1920×1080@30fps/25fps

    YUV_/p>

    640×480@30fps

    160×120@30fps

    176×144@30fps

    320×240@30fps

    352×288@30fps

    432×240@30fps

    640×360@30fps

    800×448@30fps

    800×600@25fps

    864×480@29fps

    960×720@17fps

    1024×576@20fps

    1280×720@13fps

    1600×896@8fps

    1920×1080@5fps

  • Min. Illumination0.1 Lux @ (F1.2, AGC ON)
  • Shutter Time

    PAL: 1/25 s to 1/50,000 s

    NTSC: 1/30 s to 1/50,000 s

  • Lens3.1 mm to 15.5 mm varifocal lens
  • Field of View

    Horizontal FOV: 84.9° to 20.8°

    Vertical FOV: 92.8° to 23.8°

    Diagonal FOV: 94° to 23.8°

  • Day & NightColor
  • Wide Dynamic Range≿20 dB
  • Pickup Distance5 m
  • Angle AdjustmentPan: -170° to 160°, Tilt:-28° to 28°
  • Cable Length4.5 m
  • Function
  • LED IndicatorRed: Standby, Blue: Normally Working;Blue Light Flashes Twice: Preset Setting Completed;Red Light Flashes Three Times: Restore to Factory Settings.
  • Audio Sampling Rate48 kHz
  • White BalanceAuto
  • Interface
  • Video OutputUSB 2.0
  • Audio InputBuilt-in Mic
  • Operating System

    Recommended systems

    Windows 7/8/10/11

    Android 8.1 and above version

    Linux 4.14 and above version

    macOS 10.12 and above version

    Chrome OS

  • General
  • Operating Conditions-10ℿto 50ℿ(-40°F to 122°F); Humidity: 90% or less (non-condensing)
  • Power Supply DC12V±10%
  • Consumption5.7 W MAX
  • Dimension145.3 mm × 145.6 mm × 145.8 mm (5.7" × 5.7" × 5.7")
  • Approx. 925 g (2.04 lb.)
  • Accessory
  • Packing List

    Camera (including lens cover) × 1

    Remote Control × 1

    Power Adapter × 1

    Cable × 1

    Bracket × 1

    Screws × 1

    Quick Start Guide × 1

,
  • Image Sensor2 MP CMOS
  • Signal SystemPAL/NTSC
  • Max. Resolution1920 × 1080
  • Frame Rate

    MJPEG_/p>

    640×480@30fps/25fps

    160×120@30fps/25fps

    176×144@30fps/25fps

    320×240@30fps/25fps

    352×288@30fps/25fps

    432×240@30fps/25fps

    640×360@30fps/25fps

    800×448@30fps/25fps

    800×600@30fps/25fps

    864×480@30fps/25fps

    960×720@30fps/25fps

    1024×576@30fps/25fps

    1280×720@30fps/25fps

    1920×1080@30fps/25fps

    YUV_/p>

    640×480@30fps

    160×120@30fps

    176×144@30fps

    320×240@30fps

    352×288@30fps

    432×240@30fps

    640×360@30fps

    800×448@30fps

    800×600@25fps

    864×480@29fps

    960×720@17fps

    1024×576@20fps

    1280×720@13fps

    1600×896@8fps

    1920×1080@5fps

  • Min. Illumination0.1 Lux @ (F1.2, AGC ON)
  • Shutter Time

    PAL: 1/25 s to 1/50,000 s

    NTSC: 1/30 s to 1/50,000 s

  • Lens3.1 mm to 15.5 mm varifocal lens
  • Field of View

    Horizontal FOV: 84.9° to 20.8°

    Vertical FOV: 92.8° to 23.8°

    Diagonal FOV: 94° to 23.8°

  • Day & NightColor
  • Wide Dynamic Range≿20 dB
  • Pickup Distance5 m
  • Angle AdjustmentPan: -170° to 160°, Tilt:-28° to 28°
  • Cable Length4.5 m
,
  • LED IndicatorRed: Standby, Blue: Normally Working;Blue Light Flashes Twice: Preset Setting Completed;Red Light Flashes Three Times: Restore to Factory Settings.
  • Audio Sampling Rate48 kHz
  • White BalanceAuto
,
  • Video OutputUSB 2.0
  • Audio InputBuilt-in Mic
  • Operating System

    Recommended systems

    Windows 7/8/10/11

    Android 8.1 and above version

    Linux 4.14 and above version

    macOS 10.12 and above version

    Chrome OS

,
  • Operating Conditions-10ℿto 50ℿ(-40°F to 122°F); Humidity: 90% or less (non-condensing)
  • Power Supply DC12V±10%
  • Consumption5.7 W MAX
  • Dimension145.3 mm × 145.6 mm × 145.8 mm (5.7" × 5.7" × 5.7")
  • Approx. 925 g (2.04 lb.)
,
  • Packing List

    Camera (including lens cover) × 1

    Remote Control × 1

    Power Adapter × 1

    Cable × 1

    Bracket × 1

    Screws × 1

    Quick Start Guide × 1
