HIKVISION DS-D4426RI-CAF P2.6 indoor rental LED display
Regular price
$1,000,000.00
Our standard leading time is estimated to be 40 working days, even if it is shown as in stock, please confirm this lead time before purchasing.
Couldn't load pickup availability
Get More Information
Do you have any question about the Products?Contact us now via sales@hikdistribution.com.
Do you have any question about the Products?Contact us now via sales@hikdistribution.com.
 |
 |
Ask Our Experts Text Chat | Email |
|
Important Information Regarding Order and Pricing
|
Quality Certifications: |
P2.6 indoor rental LED display
- Excellent in precision, heat dissipation, toughness, and solidity with the die-casting aluminum cabinet design.
- 500 mm × 500 mm cabinet with multiple dot pitches available and both indoor and outdoor scenarios applicable.
- Front maintenance available with the magnetic suction design, and quick front maintenance and installation achievable with the fixed installation of module at any position.
- 10-seconds replacement achievable with power supply, display controller, and adapter board integrated.
- Fast locking from the top, bottom, left, and right; 2-seconds locking for adjacent cabinets; convenient wiring with aviation plugs.
- Pendant mounting and standing available for installation.
- Free of fans and noise with excellent heat dissipation.
- High refresh rate (up to 3840 Hz) and high grey scale.
Available models:
DS-D4426RI-CAF
Product Data
- Cabinet
- Pixel ConfigurationSMD Triad LED
- Pixel Pitch CategoryP2.6
- Pixel Pitch2.604 mm
- Modules Component2 × 2
- Dimensions (W × H × D)500 mm × 500mm × 87 mm (19.69" × 19.69" × 3.43")
- Resolution192 × 192
- Area0.25 m?
- 7.7 Kg (16.97lb)
- Pixel Density147456 dots/m?
- Lamp Board Housingwith housing
- Cabinet MaterialDie-cast aluminum
- Maintenance MethodFront maintenance
- Cabinet Flatness0.2 mm
- Protection LevelFront protection level IP50
- Display
- White Balance Brightness800 cd/m?
- Color Temperature3000 K to 10000 K adjustable
- Viewing AngleHorizontal 160°, vertical 160°
- Contrast Ratio≿6000:1
- Color Uniformity≿± 0.003Cx，Cy
- Brightness Uniformity≿97＿
- Processing Performance
- Driving MethodConstant current driving
- Frame Frequency60 Hz
- Refresh Rate3840 Hz
- Grey Level16 bit
- Display Color281 trillion
- Power
- Power Supply110~220 VAC ± 15%
- Max. Consumption≿550 W/m?
- Average Consumption≿180 W/m?
- Working Environment
- Working Temperature-15-50 ℿ
- Working Humidity10%~80%RH
- Storage Humidity10%~80%RH
- Storage Temperature-20~60 ℿ
- General
- Gross Weight79 Kg (174.2 lb)
- Package Dimension (W × H × D)560 mm × 580 mm × 670 mm (6 IN 1)
- LifespanLamp 100,000 hours
- Pixel ConfigurationSMD Triad LED
- Pixel Pitch CategoryP2.6
- Pixel Pitch2.604 mm
- Modules Component2 × 2
- Dimensions (W × H × D)500 mm × 500mm × 87 mm (19.69" × 19.69" × 3.43")
- Resolution192 × 192
- Area0.25 m?
- 7.7 Kg (16.97lb)
- Pixel Density147456 dots/m?
- Lamp Board Housingwith housing
- Cabinet MaterialDie-cast aluminum
- Maintenance MethodFront maintenance
- Cabinet Flatness0.2 mm
- Protection LevelFront protection level IP50
- White Balance Brightness800 cd/m?
- Color Temperature3000 K to 10000 K adjustable
- Viewing AngleHorizontal 160°, vertical 160°
- Contrast Ratio≿6000:1
- Color Uniformity≿± 0.003Cx，Cy
- Brightness Uniformity≿97＿
- Driving MethodConstant current driving
- Frame Frequency60 Hz
- Refresh Rate3840 Hz
- Grey Level16 bit
- Display Color281 trillion
- Power Supply110~220 VAC ± 15%
- Max. Consumption≿550 W/m?
- Average Consumption≿180 W/m?
- Working Temperature-15-50 ℿ
- Working Humidity10%~80%RH
- Storage Humidity10%~80%RH
- Storage Temperature-20~60 ℿ
- Gross Weight79 Kg (174.2 lb)
- Package Dimension (W × H × D)560 mm × 580 mm × 670 mm (6 IN 1)
- LifespanLamp 100,000 hours
